Slotted Angle Racks
WAREHOUSE RACK
SUPERMARKET SHELVING
Specialized Supermarket Display Racks
- Light-Duty Efficiency: Ingeniously optimized to support versatile, safe loading capacities ranging from 50kg up to 150kg per layered tier.
- Fast Boltless Assembly: Precision roll-formed components feature an advanced interlocking rivet layout or standard nut-and-bolt options for rapid, tools-free facility installation.
- Space Saving Layouts: Completely customizable profile dimensions make this configuration ideal for small retail stockrooms, corporate offices, e-commerce fulfillment spaces, and light workshops.
- B2B Factory Support: Enjoy direct factory wholesale prices, flexible low MOQ trial container limits, fast global fulfillment times, and complete dimensional custom adaptation.
Slotted Angle Racks Dimension
*Note:Fully Customizable: Sizes, colors, and finishes can be tailored to your needs. Contact us for more styles and bespoke solutions!
| Item | Slotted Angle Rack |
| Material | High-grade Q235B Cold-rolled Steel |
| Product Size | Length: 600/900/1000/1200/1500 mm Width: 300/400/450/500/600 mm Height: 1500/1800/2000/2200/2500 mm |
| Thickness | Angle Post: 1.2/1.5/1.8/2.0 mm Shelf Deck: 0.8/1.0/1.2 mm |
| Load Capacity | 50-200 kg per layer (customizable up to 300kg/layer) |
| Layers | 2-8 adjustable layers (custom made available) |
| Color | Standard RAL colors (Blue/Grey/Black/White); Custom RAL color available |
| Surface Treatment | Electrostatic powder coating / Galvanized (anti-rust finish) |
| Feature | Easy assembly & disassembly; Adjustable shelf height; Light-duty multi-purpose storage; Boltless connection design |
| OEM/ODM | Accepted |
| Certification | CE / ISO9001 |
| Use Area | Warehouse, office, retail store, home storage, factory workshop |
| Structure | Knock-down boltless structure; Easy to install, transport and relocate |
| Function | Storage and organization of small parts, boxes, cartons, tools and general goods |
You May Also Need
FAQ About Slotted Angle Racks
Q1: Can LANTOO slotted angle racks be customized for semi-industrial or automotive environments?
A: Yes, absolutely. While highly popular for light-duty commercial retail back stockrooms, we custom-fabricate our slotted angle rack configurations utilizing a heavy-gauge Q235B cold-rolled steel post option (up to 2.0mm thickness) paired with a tough anti-rust galvanized or scratch-resistant powder coat. This makes them perfectly resilient against oils, moisture, and rough handling in automotive small-parts garages and light workshops.
Q2: What is the maximum safe load capacity, and can it be upgraded?
A: Our regular configurations safely support 50kg to 150kg per layered level under a Uniformly Distributed Load (UDL). If your retail setup handles heavier inventory, we can seamlessly upgrade the steel deck plate thickness to 1.2mm or spot-weld custom integrated steel reinforcement ribs underneath each deck layer to achieve a certified 300kg/layer capacity without expanding outer column dimensions.
Q3: Do these shelving units require specialized tools or bolting to the floor for stability?
A: LANTOO shelving configurations offer both an advanced boltless rivet interlocking option and classic heavy-duty nut-and-bolt options. For standard stockroom heights under 1500mm, a freestanding configuration is incredibly stable. For setups exceeding 2000mm or deployed in high-traffic logistics paths, we highly recommend utilizing our pre-punched steel footplates to anchor the posts directly into the concrete floor for maximum safety compliance.
